Items	Unit	SYF01	SYF03	SYF05
Workpiece grinding diameter	mm	20-350	50-500	50-500
Center distance	m	2.3.4	3.4	3.4
Supporting weight	kg	1000	3000	5000
Convexity (concave) (Radius)	mm	≤1.5	≤1.5	≤1.5
Grinding wheel specification (Outer dia. ×Inner dia. ×Width)	mm	600×205×50	600×305×60	750×305×75
Grinding wheel surface speed	M/S	35(45)	35(45)	35(45)
Headstock speed	rpm	100	100	100
Saddle speed	mm/min	4000	4000	4000
Steady rest supporting range	mm	50-260	50-300	50-300
Headstock motor power	kW	12	22	22
Grinding carriage motor power	kW	18.5	18.5	18.5
Measuring range of measuring stand	mm	-	-	-
Measuring range of measuring stand

Note:

1. The data in the above table are available at the customers’ request;

2. Model explanation: For example SYF03X40;

SYF---The product of Shanghai Shunyu, workpiece movable CNC roll grinding machine (without auto-measuring system);

03----Max. workpiece weight 3 tons;

40----Center distance or max. grinding roll length 4 meters;

A ----A type product, mainly used for aluminum foil industry;

B ----B type product, mainly used for metallurgy, cold rolling industry.
